規格參數
確認接口類型、端口速率、傳輸距離、單/雙端口、功耗、安裝形態和是否需要配套線纜或光模塊。
RUCKUS ICX 8200通過多達8個25 GbE連接埠用於上行鏈結或堆疊、PoE++（802.3bt）、VXLAN以及高級L2/L3功能，進一步提升了標準
以及市場領先的堆疊密度，每堆疊最多可容納12個交換器。此外，RUCKUS ICX 8200還融合了企業級功能，
可堆疊解決方案兼具可管理性、性能和可靠性，同時具備靈活性、成本效益和「隨增長而付費」的可擴展性。
RUCKUS ICX 8200-48ZP2-E2 RUCKUS ICX 8200交換器，32個10/100/1000 Mbps PoE+連接埠，16個100/1000/2500 Mbps RJ-45 PoE++連接埠，4個25 GbE SFP28堆疊/上行連接埠，1480 W PoE預算，熱插拔電源和風扇，包括兩個電源和兩個風扇，三年遠程技術支援（TAC）
支援。不包括電源線。
| RUCKUS ICX 8200-48ZP2-E2 | |
| Switching capacity (data rate, full duplex) | 334 Gbps |
| Forwarding capacity (data rate, full duplex) | 254 Mpps |
| 10/100/1000 Mbps RJ45 ports | 32 |
| 100/1000 Mbps/2.5 Gbps RJ45 downlinks (full duplex only) | 16 |
| 1/10 Gbps SFP/SFP+ uplinks | - |
| 1/10/25 Gbps SFP/SFP+/SFP28 uplinks | 4 |
| PoE/PoE+ 802.3at ports | 32 |
| Dual hot-swap power supplies and fan modules | yes |
| Max PoE Class 3 ports (15.4 W per port) | 48 |
| Max PoE+ Class 4 ports (30 W per port) | 24 (1 PSU) 48 (2 PSU) |
| Maximum PoE++ Class 6 ports (60 W per port) | 12 (1PSU) 16 (2 PSU) |
| Maximum PoE++ Class 8 Ports (90 W per port) | 8(1PSU) 16 (2PSU |
| Advanced IPv4/v6 Layer 3 (OSPF, VRRP, VRF, GRE, PIM, PBR) | With License |
| Aggregated stacking bandwidth (data rate, full duplex) | 1.2 Tbps |
| Stacking density (maximum switches in a stack) | 12 |
| Stacking ports (maximum ports usable for stacking) | Up to 4×25 GbE SFP28 |
| Maximum stacking distance (distance between stacked switches) | 10 km |
